Transformator Automower

Automower® power supplies / transformers

The Automower transformer supplies power to the charging station and is connected to a standard electrical outlet, extended with a low-voltage cable.
It provides power to the robot during charging and to the circuit board in the charging station, which in turn supplies power out to the loop, allowing the Automower to respond to the electromagnetic field created by the loop and function correctly.
If the transformer is damaged, the Automower loses contact with the loop and immediately displays an error message 'No loop signal'. With the help of our guide, you can troubleshoot your Automower transformer with a multimeter without further knowledge. It is also noticeable that the Automower transformer might be defective if the light in the charging station is off. It should always be lit as long as everything is correctly connected. If it lights up green, it means that the loop is functioning and that everything is correct.
A blue flashing light indicates that there is a loop break, for example. You can read more about what the different colours in the charging station mean here.
Power Supply EU 435X AWD,440,450X,520,550
€265.90
5473070-01
In stock
Buy
Power Supply USA 435X AWD,440,450X,520,550

News

€265.90
5473070-04
Shipped in 2-4 business days
Buy
Power supply EU 305 R40/R45/R50li
€74.99
5877970-01
In stock
Buy
Power Supply EU 330X, 430X
€168.90
5996626-01
In stock
Buy
Power Supply 265 ACX EU
€194.90
5782753-01
Out of stock
Buy
Power supply Automower 230ACX
€148.90
5010044-01
In stock
Buy
Power supply 220AC,Solar,R160
€114.90
5351237-01
In stock
Buy
Charging and loop signal generator unit, 210C
€102.90
5449770-01
Shipped in 2-4 business days
Buy
Power supply EU 308 R70/R80Li
€83.59
5844089-01
In stock
Buy
Power supply EU 260ACX
€185.90
5227824-01
In stock
Buy

Broken Automower Transformer

If your Automower transformer is broken, we first recommend that you measure whether it is providing any voltage with a multimeter. If no voltage can be detected, then the transformer should be replaced. The Automower transformer is not easy to repair as it is encapsulated to withstand weather, and we do not recommend attempting to open it. If the light in your Automower charging station is off despite the transformer providing the correct voltage when measured, we primarily recommend trying to connect the transformer directly to the charging station, without the extension cable.*
*Note: Does not work for Automower 440, 450X, or 550. If the charging station still does not light up after connecting the transformer directly to it, it is most likely the circuit board that has failed and needs to be replaced.
